HVAC System Central Packaged Rooftop Air Conditioner

Minimum Order Quantity : 1 unit Price : 1000USD-5000USD/unit
Packaging Details : standard pallet packing Delivery Time : 30-60days
Payment Terms : L/C, T/T, Western Union Supply Ability : 50 Containers Per Month
Place of Origin: CHINA Brand Name: VENTECH
Certification: CE Model Number: Rooftop package unit

Detail Information
Product Name: Rooftop Package Unit Keyword: Central Air Conditioner
Working Temperature: -40 To 120 Degree Length: MAX:50ft
Payment Term: TT,LC Certificate: CE
Sample: Yes(in Charge) Busiess Type: Factory
High Light:

Central Packaged Rooftop Air Conditioner

,

HVAC System Packaged Rooftop Air Conditioner

Product Description

A Central Air Conditioner Price For HVAC System Rooftop Package Unit Cost

VENTECH(Vcare) Rooftop pacakge unit



Cooling,Heat pump, Electrical heating

Parameter Cooling capacity Heating capacity Outdoor body size Outdoor weight Indoor body size Indoor weight Airflow ESP Consumed power
(KW)		 Noise
≤dB(A)
Model kW kW L W H kg L W H kg (m3/h) (Pa) Cooling
VWD-118F 117.9 117.6 1800 1800 2230 1900 2500 1800 1800 450 20100 250 45.01 77
450 46.75 77
VWD-126F 125.9 128 1800 1800 2230 1900 2500 2000 1800 500 22800 250 51.04 7S
450 52.82 78
VWD-134F 134.1 138.5 1800 1800 2230 1900 2500 2200 1800 650 25400 300 55.63 79
500 57.88 79
VWD-144F 143.9 149.1 1800 1800 2230 1900 2500 2400 1800 700 28100 300 59.67 79
500 61.94 80
VWD-177F 176.8 176.9 3000 1700 2230 2300 2500 2100 2200 1000 29900 350 69.07 80
550 71.94 80
VWD-185F 184.9 186.9 3000 1700 2230 2300 2500 2200 2200 1100 31600 350 74.82 80
550 77.75 81
VWD-193F 199 197.3 3000 1700 2230 2300 2500 2400 2300 1200 37700 350 82.51 81
550 85.66 81
VWD-201F 201.2 207.8 3000 1700 2230 2300 2500 2600 2300 1360 41300 350 85.66 82
550 89.33 82
VWD-216F 215.9 223.7 3000 1900 2230 2500 2600 2400 2500 1750 42100 350 89.81 83
550 93.49 83
VWD-268F 268.3 277 3050 2100 2340 3000 2600 2700 2600 1960 48600 450 118.14 84
650 122.07 85
VWD-288F 287.9 298.2 3550 2100 2340 3400 2600 2900 2500 2150 51400 500 124.52 85
700 129.37 85
VWD-350F 350 359.4 3550 2100 2340 3700 2600 2900 2800 2300 57400 500 150.58 86
700 155.5 86
VWD-402F 402.4 415.5 6000 1700 2230 4200 2600 3200 2800 2460 64000 500 168.57 M
700 174.93 87
VWD-432F 431.8 447.4 6000 1900 2230 5400 2600 3400 2800 2560 68400 550 180.09 B7
850 184.84 8S
VWD-528F 527.8 544.6 6000 2300 2230 6000 2600 4000 2900 2750 79300 550 214.36 88
850 222.37 89
VWD-576F 575,7 596.4 7100 2100 2340 6500 3300 4400 2900 3200 88600 600 245.3 89
900 253.92 89





Single Split Ductless Air Conditioner

The split ductless AC is the most popular variant opted by households. The AC is “split” into two components – the indoor unit and outdoor unit.

The outdoor unit (ODU) is the condenser unit that contains the compressor and a heat exchanging coil. It is mounted outside the house premises. The outdoor unit needs to be in the open air to function correctly. It can be installed on the wall or attached to the ground.

The indoor unit (IDU) has a coil that cools down and extracts heat from your room. The indoor unit is wall-mounted at the height of at least 8-9 feet from the floor. This ensures that it does not consume usage space in your room.

The indoor and outdoor units are connected through pipes that carry the refrigerant. The installation comprises mounting the indoor and outdoor units and connecting the pipes. Once the technicians confirm that the units have been installed correctly, they fill refrigerant in the system.

Manufacturers provide a long list of features – horizontal and vertical swing, sleep tracking, automatic temperature adjustment (often called comfort mode), mosquito repellant system, air filtering systems, and many more. Today’s smart split AC comes with built-in Wi-Fi and can be controlled using a mobile phone or a smart assistant like Alexa or Google Home.

Heat-Pump: There are split units that have both cooling and heating facility. Since the AC is a heat pump, if the flow is reversed, the indoor unit acts as a heater. Such dual-purpose units serve well in areas that have extreme temperatures throughout the year. . Aircon service for these types of aircon is moderatly easy, provided there is access to the compressor unit.





❤ Want to learn more about Vcare Wholehouse air conditioner,please contact us by email directly.

Email:karen@chinaventech.com

Tel:0086 13620119598
