Home Central Air Conditioner For HVAC System Rooftop Package Unit E-Catalogue

Minimum Order Quantity :	1 unit	Price :	1000USD-5000USD/unit
Packaging Details :	standard pallet packing	Delivery Time :	30-60days
Payment Terms :	L/C, T/T, Western Union	Supply Ability :	50 Containers Per Month

Place of Origin:	CHINA	Brand Name:	VENTECH
Certification:	CE	Model Number:	Rooftop package unit

Detail Information
Package:	Pallet Packing	Model:	Rooftop Package Unit
Working Temperature:	-40 To 120 Degree	Length:	MAX:50ft
Payment Term:	TT,LC	Quality:	Superior
Sample:	Yes(in Charge)	Trade Mark:	VENTECH
High Light:	CE Home Central Air Conditioner , Electrical Heating Rooftop Package Unit

Product Description

Central Air Conditioner Brands For HVAC System Rooftop Package Unit E-Catalogue

VENTECH(Vcare) Rooftop pacakge unit

Cooling,Heat pump, Electrical heating

Parameter	Cooling capacity	Heating capacity	Outdoor body size			Outdoor weight	Indoor body size			Indoor weight	Airflow	ESP	Consumed power (KW)	Noise ≤dB(A)
Model	kW	kW	L	W	H	kg	L	W	H	kg	(m3/h)	(Pa)	Cooling
VWD-118F	117.9	117.6	1800	1800	2230	1900	2500	1800	1800	450	20100	250	45.01	77
												450	46.75	77
VWD-126F	125.9	128	1800	1800	2230	1900	2500	2000	1800	500	22800	250	51.04	7S
												450	52.82	78
VWD-134F	134.1	138.5	1800	1800	2230	1900	2500	2200	1800	650	25400	300	55.63	79
												500	57.88	79
VWD-144F	143.9	149.1	1800	1800	2230	1900	2500	2400	1800	700	28100	300	59.67	79
												500	61.94	80
VWD-177F	176.8	176.9	3000	1700	2230	2300	2500	2100	2200	1000	29900	350	69.07	80
												550	71.94	80
VWD-185F	184.9	186.9	3000	1700	2230	2300	2500	2200	2200	1100	31600	350	74.82	80
												550	77.75	81
VWD-193F	199	197.3	3000	1700	2230	2300	2500	2400	2300	1200	37700	350	82.51	81
												550	85.66	81
VWD-201F	201.2	207.8	3000	1700	2230	2300	2500	2600	2300	1360	41300	350	85.66	82
												550	89.33	82
VWD-216F	215.9	223.7	3000	1900	2230	2500	2600	2400	2500	1750	42100	350	89.81	83
												550	93.49	83
VWD-268F	268.3	277	3050	2100	2340	3000	2600	2700	2600	1960	48600	450	118.14	84
												650	122.07	85
VWD-288F	287.9	298.2	3550	2100	2340	3400	2600	2900	2500	2150	51400	500	124.52	85
												700	129.37	85
VWD-350F	350	359.4	3550	2100	2340	3700	2600	2900	2800	2300	57400	500	150.58	86
												700	155.5	86
VWD-402F	402.4	415.5	6000	1700	2230	4200	2600	3200	2800	2460	64000	500	168.57	M
												700	174.93	87
VWD-432F	431.8	447.4	6000	1900	2230	5400	2600	3400	2800	2560	68400	550	180.09	B7
												850	184.84	8S
VWD-528F	527.8	544.6	6000	2300	2230	6000	2600	4000	2900	2750	79300	550	214.36	88
												850	222.37	89
VWD-576F	575,7	596.4	7100	2100	2340	6500	3300	4400	2900	3200	88600	600	245.3	89
												900	253.92	89

Ducted AC system

Ducted Air Conditioners are used more often at offices than they’re used at homes. There is a central cooling/heating unit, and a network of ducts passes through false ceilings. The ducts vent to the rooms.

Every room has its own thermostat, which allows for different temperature “zones” to be created on the premises. The flow of conditioned air is stopped when the set temperature is reached.

Ducted AC systems appear to be seamlessly integrated with the home or office. It is better to plan for a ducted system when the structure is being built or renovated.

A big area is required to keep the cooling unit/furnace, and the network of ducts requires careful planning. The vents inside the rooms look better if planned rather than a retrofit.

❤ Want to learn more about Vcare Wholehouse air conditioner,please contact us by email directly.

Email:karen@chinaventech.com

Tel:0086 13620119598
