Air Flow 12000m3/H 6 Ton Central Air Unit Dual Refrigeration System
Contact Person : Daisy
Phone Number : 86-13425728677
WhatsApp : +8613425728677
Minimum Order Quantity : | 1 unit | Price : | 1000USD-5000USD/unit |
---|---|---|---|
Packaging Details : | standard pallet packing | Delivery Time : | 30-60days |
Payment Terms : | L/C, T/T, Western Union | Supply Ability : | 50 Containers Per Month |
Place of Origin: | CHINA | Brand Name: | VENTECH |
---|---|---|---|
Certification: | CE | Model Number: | Modular air handing unit |
Detail Information |
|||
Product Name: | Modular Air Handing Unit | Working Pressure: | CE |
---|---|---|---|
Working Temperature: | Different Working Pressure | Retun Air: | DB 27℃/WB 19.5℃ |
Model: | Rooftop Package Unit | Feature: | Adjustable |
Standard: | International Standard | Trademark: | VENTECH |
High Light: | Central Air Conditioner Components,Rooftop Package Unit Air Conditioner Components |
Product Description
Tech | Airflow (m3/h) |
Cooling coil | Vapor coil | ||||||||
Return air condition capacity(kW) | Fresh air condition capacity kW) | Return ar heating(kW) | |||||||||
Model | 2-row | 4-row | 6-row | 8-row | 2-row | 4-row | 6-raw | 8-raw | 1-row | 2-raw | |
VAH001 | 1000 | 3.8 | 6.2 | 7.9 | 8.8 | 7.7 | 12.6 | 16.4 | 18.4 | 11.4 | 21.2 |
VAH002 | 2000 | 7.3 | 12.0 | 15.3 | 17.1 | 15.6 | 25.6 | 33.3 | 37.4 | 22.9 | 42.8 |
VAH003 | 3000 | 11.6 | 19.0 | 24.2 | 27.0 | 23.2 | 38.1 | 49.6 | 47.7 | 34.4 | 64.3 |
VAH004 | 4000 | 14.1 | 23.1 | 29.5 | 32.9 | 31.3 | 51 4 | 66.9 | 75.1 | 45.1 | 84.2 |
VAH005 | 5000 | 17.7 | 29.0 | 37.0 | 41.3 | 39.3 | 64.5 | 84.0 | 94.3 | 56.4 | 104.4 |
VAH006 | 6000 | 21.7 | 35, | 45.3 | 50.6 | 43.3 | 71.1 | 98.6 | 104.0 | 87.6 | 126.5 |
VAH007 | 7000 | 26.3 | 43.1 | 55.0 | 61.4 | 53.6 | 88.0 | 114.6 | 128.7 | 78.8 | 147.5 |
VAH008 | 8000 | 31.1 | 50.9 | 64.9 | 72.4 | 63.2 | 103.7 | 135.0 | 151 6 | 90.0 | 168.4 |
VAH009 | 9000 | 34.5 | 56.5 | 72.0 | 80.3 | 69.9 | 114.7 | 149.3 | 167.7 | 101.2 | 189.4 |
VAH010 | 10000 | 37.6 | 61.6 | 78.5 | 87.6 | 80.1 | 131.4 | 171.1 | 192.1 | 112.4 | 210.4 |
VAH012 | 12000 | 45.4 | 74.4 | 94.9 | 105.9 | 93.2 | 152.9 | 189.1 | 223.6 | 134.8 | 252.3 |
VAH014 | 14000 | 53.1 | 87.0 | 110.9 | 123.8 | 110.9 | 182.0 | 237.0 | 266.2 | 157.2 | 294.2 |
VAH016 | 16000 | 61.8 | 101.2 | 129.0 | 144.0 | 129.7 | 212S | 277.1 | 311.2 | 179.6 | 336.2 |
VAH018 | 18000 | 70.7 | 115.8 | 147.6 | 164.7 | 148.1 | 243.0 | 316.4 | 355.3 | 202.0 | 378.1 |
VAH020 | 20000 | 80.4 | 131.7 | 167.9 | 187.4 | 164.3 | 269.6 | 351.0 | 394.2 | 225.6 | 421.2 |
VAH022 | 22000 | 84.1 | 137.8 | 176.7 | 196.1 | 170.4 | 279.6 | 364.0 | 408.8 | 252.3 | 467.5 |
VAH024 | 24000 | 92.3 | 151.2 | 192.8 | 215.2 | 194.5 | 319.2 | 415.6 | 466.7 | 266.3 | 500.9 |
VAH026 | 26000 | 100.1 | 164.0 | 200.1 | 233.3 | 210.2 | 344.9 | 449.0 | 504.2 | 293.3 | 547.6 |
VAH028 | 28000 | 107.8 | 178.6 | 225.2 | 251.3 | 220.3 | 361.5 | 470.7 | S28.6 | 310.6 | 564.4 |
VAH030 | 30000 | 117.0 | 191.6 | 244.3 | 272.6 | 239.7 | 303.3 | 512.1 | 575.1 | 332.7 | 822.8 |
VAH035 | 36000 | 136.3 | 223.3 | 284.7 | 317.7 | 268.2 | 440.1 | 573.0 | 643.5 | 388.1 | 726S |
VAH040 | 40000 | 156.1 | 256.7 | 326.0 | 363.8 | 307.5 | 504.6 | 657.0 | 737.3 | 443.5 | 830.2 |
VAH045 | 45000 | 169.2 | 277.2 | 363.4 | 394.4 | 364.4 | 581.6 | 757.2 | 850.3 | 498.9 | 933.9 |
VAH050 | 50000 | 181.8 | 297.8 | 379.7 | 423.7 | 393.3 | 645.4 | 840.3 | 943.7 | 564.3 | 1037.6 |
VAH055 | 55000 | 203.4 | 333.2 | 424.8 | 474.1 | 436.7 | 716.6 | 933.0 | 1047.8 | 609.7 | 1141.3 |
VAH060 | 60000 | 226.8 | 371.5 | 473.7 | 528.6 | 481.6 | 790.3 | 1029.0 | 1156.6 | 665.1 | 1245.0 |
VAH070 | 70000 | 266,7 | 436.9 | 667.0 | 621.6 | 548.2 | 899.6 | 1171.3 | 1315.4 | 775.9 | 1452.4 |
VAH080 | 80000 | 307.2 | 503.2 | 641.6 | 716.0 | 636.6 | 1044.7 | 1380.2 | 1527.5 | 886.7 | 1659.9 |
VAH090 | 90000 | 345.7 | 566.3 | 722.0 | 805.8 | 714.5 | 1172.5 | 1526.6 | 1714.4 | 997.5 | 1867.3 |
VAH100 | 100000 | 384 1 | 629.2 | 802.2 | 895.3 | 786.4 | 1290.5 | 1680.2 | 1886.9 | 1108.3 | 2074.7 |
VAH110 | 110000 | 398.4 | 652.6 | 832.1 | 928.6 | - | - | - | - | 1219.1 | 2282.1 |
VAH120 | 120000 | 41.3 | 678.8 | 865.2 | 985.6 | - | - | - | - | 1329.9 | 2489.5 |
VAH130 | 130000 | 452.9 | 741.9 | 945.9 | 1055.6 | - | - | - | - | 1440.7 | 2696 9 |
VAH140 | 140000 | 491.8 | 806.6 | 1027.1 | 1146.2 | - | - | - | - | 1551.5 | 2904.4 |
VAH150 | 150000 | 523.7 | 857.8 | 1083.7 | 1130.6 | - | - | - | - | 1662.3 | 3111.8 |
VAH160 | 160000 | 557.2 | 912.7 | 1163.7 | 1298.7 | - | - | - | - | 1745.0 | 3279.3 |
VAH170 | 170000 | 586.3 | 960.4 | 1224.5 | 1366.5 | - | - | - | - | 1854.0 | 3484.3 |
VAH180 | 180000 | 616.0 | 1009.0 | 1296.5 | 1435.7 | - | - | - | - | 1963.1 | 3689.2 |
VAH190 | 190000 | 647.1 | 1060.0 | 1351.5 | 1508.3 | - | - | - | - | 2072.1 | 3894.2 |
VAH200 | 200000 | 678.5 | 1111.4 | 1417.0 | 1581.4 | - | - | - | - | 2143.6 | 4061.5 |
VAH220 | 220000 | 736.4 | 1206.2 | 1537.9 | 1716.3 | - | - | - | - | 2399.3 | 4609.0 |
VAH250 | 2S0000 | 817.6 | 1339.2 | 1707.5 | 1905.6 | - | - | - | - | 2879.5 | 5029.9 |
*Cold water cooling condition: return air :DB 27℃/WB 19.5℃; fresh air DB35℃/WB28℃;cold water inlet/outlet 7℃/12℃.
*Heat water cooling condition: return air :DB 15℃/fresh air DB 7℃;inlet/outlet water: 60℃/50℃.
*Heating retur air condition: DB 15℃,fresh air:DB 7 ℃/vapor inlet:115℃,pressure:0.2Mpa.
Programmable thermostats
Setting your smart or programmable thermostat at the right temperature can reduce your cooling costs by about 10 percent. The right temperature varies on your comfort level, but start by setting it at 78° F and experiment until you find the sweet spot. You’ll save about 3 percent on your utility bill for every degree you raise the set temperature for your central air, according to the Department of Energy. And keep in mind that using a box or ceiling fan, which costs little to run, can make you feel 3° F to 4° F cooler.
